Click Lock Metal BELPROFILE Click Waves
BELPROFILE Click Waves is a high-performance click-joint roofing sheet system designed for projects requiring high structural rigidity in demanding climatic conditions. The profile retains a modern aesthetic inspired by standing seam roofing, complemented by a structure optimised for strength.
The best-performing coating system for sheet metal products, applied in 10 layers and offering the longest lifespan.
Special paint applied in 7 layers, each with a role in protecting the sheet over time; its sand-grain texture gives superior hardness and resistance and ensures greater thermal comfort in summer.
Matt polyester paint that gives the colour greater stability over time.
Glossy polyester paint, the traditional way of protecting metal products.
About Click Waves
The Click joining system enables fast and secure installation of the panels, with no visible fasteners. The perforated side edge used for fixing is pressed and positioned beneath the overlapping panel, so that the screws remain protected and concealed within the system.
The seams are designed with a difference of 5 mm between the covering element and the supporting one, and the lower edge of the panel is pre-cut and folded in the factory, reducing installation time and ensuring a uniform finish.
The Waves profile includes additional stiffening in the form of a micro-sinusoidal profile across the panel surface, which significantly increases rigidity and resistance to deformation - which is why it is the profile recommended for roofs exposed to strong winds or large roof areas. Made from pre-painted galvanised steel sheet, the Click Waves system is part of a complete Click roofing system that is safe, durable and attractive.
- A solution suitable for most types of roof.
- Can also be used for cladding.
- Lightweight and durable.
- Flat profile.
- The fold for fixing to the eaves flashing is formed automatically (less labour and therefore lower installation costs).
- Installed on a ventilated structure, like metal roof tiles.
Technical data
- Panel surface
- Micro-sinusoidal stiffening
- Effective width
- 500 mm
- Total width
- 540 mm
- Profile depth
- 25 mm
- Panel length
- 1000–6000 mm
- Batten spacing
- 250–300 mm
- Minimum roof pitch
- 12° (21%)
- Sheet thickness
- 0.50 mm
- Weight
- 4 kg/m²
- Recommended wind exposure
- Strong; large roofs
- Installation and formats
- Concealed fixing (click joint) · Lower edge prepared in the factory · Also suitable for cladding
- Zinc coating
- 225–275 g/m²
- Finishes
- PrinTech, BigStone, Matt, SunClear
- Colours
- Spanish GRANADA, Spanish ANDALUSIA, STONEGRAY, METALGRAY, RAL 7024 (graphite grey), RAL 8017 (chocolate brown), RAL 8019 (grey brown), RAL 9005 (jet black), RAL 8004 (copper brown), RAL 3009 (oxide red), RAL 7016 (anthracite grey)
- Warranty
- up to 40 years
